Eco Waterbase Wind Sign
• Waterproof IP56
• Suitable for outdoor conditions between -15ºC/5ºF to +50ºC/122ºF.
• Double sided stopper as pavement sign.
• Click clack snap open system provides easy using.
• Suitable for windy and rainy conditions.
• Each product comes with instruction sheet.
• for optional header use, header enabled frames must be ordered.
SIZES
20″ X 30″, 22″ X 28″ , 24″ X 36″ , 30″ X 40″ , 40″ X 60″
Product Specifications
| MATERIAL : Silver anodised aluminium | ||||||
|---|---|---|---|---|---|---|
| ARTICLE | EXTERNAL (x-y) | POSTER | COPY | H1 | X1 | D1 |
| UEWM000N22 | 25.03” X 31.03” | 22” X 28” | 21.53” X 27.53” | 45.08” | 27.56” | 21.35” |
| UEWM000N23 | 23.03” X 33.03” | 20” X 30” | 19.53” X 29.53” | 46.85” | 27.56” | 21.65” |
| UEWM000N24 | 27.03” X 39.03” | 24” X 36” | 23.53” X 35.53” | 53.35” | 32.28” | 25.59” |
| UEWM000N34 | 33.03” X 43.03” | 30” X 40” | 29.53” X 39.53” | 57.28” | 32.28” | 25.59” |
| UEWM000N46 | 43.03” X 63.03” | 40” X 60” | 39.53” X 59.53” | 74.02” | 39.37” | 29.53” |
| MAIN BODY | WATER BASE | ||
|---|---|---|---|
| WEIGHT | PACKING SIZE | WEIGHT | PACKING SIZE |
| WITH PACKING | *W X H X D | WITH PACKING | *W X H X D |
| 17.526 lbs | 26.18” X 40.55” X 1.57” | 17.857 lbs | 22.44” X 28.35” X 9.45” |
| 17.526 lbs | 24.21” X 43.31” X 1.57” | 17.857 lbs | 22.44” X 28.35” X 9.45” |
| 19.731 lbs | 27.95” X 48.82” X 1.57” | 25.353 lbs | 33.07” X 26.38” X 9.45” |
| 24.912 lbs | 34.45” X 53.15” X 1.57” | 25.353 lbs | 33.07” X 26.38” X 9.45” |
| 37.478 lbs | 39.96” X 67.52” X 1.57” | 30.864 lbs | 40.16” X 30.31” X 9.45” |
* W:Width H: Height D: Depth
Poster Thicknesses
ACCESSORIES
Eco Waterbase Wind Sign Product Print Templates
Eco Waterbase Wind Sign Product Assembly Sheets
Eco Waterbase Wind Sign Product Technical Data Sheets
Eco Waterbase Wind Sign Product Certificates & Warranty
Product in Place
Eco Waterbase Wind Sign Product Videos
